10′ x 10′ Pacific Shoring MAPS Aluminum Trench Box
The 10′ x 10′ Pacific Shoring MAPS is a modular aluminum trench protection system designed for contractors who need a large, configurable aluminum trench box for underground utility, pipeline, municipal, and excavation work.
Unlike a conventional welded aluminum trench shield, the MAPS system is constructed from modular aluminum panels, corner posts, and spreaders. This modular design allows the system to be configured and adapted for different excavation requirements while providing contractors with a lighter alternative to many comparable steel trench boxes.
The 10′ x 10′ configuration provides 10 feet of shield height and 10 feet of panel length. The standard two-sided configuration priced here includes six adjustable spreaders with a 35- to 48-inch adjustment range. The total weight of the system as configured here is 2,206 lbs. Other spreader sizes are available to accommodate different trench widths and working-clearance requirements.
Why Choose the MAPS Modular System?
The MAPS design is particularly useful when contractors need more configuration flexibility than a conventional welded aluminum trench shield. Modular panel sections, corner posts, and spreader components allow the system to be assembled for different excavation layouts, including standard two-sided boxes and specialized three- or four-sided configurations.
Why Choose the MAPS 10×10 System?
The Pacific Shoring MAPS 10′ x 10′ configuration is a strong option for contractors who need a tall, long modular aluminum trench protection system with flexibility for different excavation layouts. Its 10-foot height and 10-foot panel length provide substantial protected working space while retaining the modular advantages of the MAPS design.
The system is built from stackable 2-foot-tall tongue-and-groove aluminum panel sections, allowing the shield to be assembled from modular components rather than relying on a single welded panel structure. This makes the MAPS system well suited for contractors who value configuration flexibility, component replacement options, and the ability to use the same modular system across different project requirements.
The 10×10 MAPS can be configured as a standard two-sided trench shield and can also be adapted for three-sided or four-sided applications with the appropriate additional components. Adjustable spreader options allow the system width to be selected based on project needs.
For contractors comparing large aluminum trench box options, the MAPS 10×10 offers a combination of size, modular construction, configurable spreader widths, and multiple configuration possibilities. Final system selection and use should be based on jobsite conditions, manufacturer tabulated data, and evaluation by the project’s Competent Person.
10′ x 10′ MAPS Specifications
-
Size: 10′ high x 10′ long
-
Material: Aluminum
-
Manufacturer: Pacific Shoring
-
Product Line: MAPS Modular Aluminum Panel System
-
Spreader Width: Selectable based on job requirements
- Total weight of the system configured here is 2,206 lbs.
-
Shipping Locations: California, Texas, and North Carolina
-
Manufacturer tabulated data provided with the trench protection system
Soil Depth Ratings
The current 10′ x 10′ MAPS configuration is rated as follows:
-
A25 Soil: 25 ft.
-
B45 Soil: 25 ft.
-
C60 Soil: 20 ft.
-
C80 Soil: 15 ft.
Depth ratings and system configuration must be reviewed in accordance with the manufacturer’s tabulated data. Soil conditions, excavation conditions, surcharge loads, system configuration, and other jobsite factors can affect the proper selection and use of a trench protective system.
A Competent Person must evaluate excavation conditions and select and use protective systems in accordance with applicable OSHA requirements and manufacturer tabulated data.
Modular MAPS Construction
The Pacific Shoring MAPS system uses modular aluminum panels, corner posts, and connected spreaders or struts. The modular construction gives contractors more configuration flexibility than a conventional one-piece welded trench shield.
Depending on the system configuration and project requirements, MAPS equipment can be assembled in two-sided, three-sided, and four-sided arrangements. The modular design can be particularly useful for utility work, structures, pits, and excavations where a standard two-wall trench box configuration may not be the best fit.
Contact Iron Lot to discuss the intended application before ordering components for a three-sided, four-sided, stacked, or other specialized configuration.
Adjustable Spreader Options
Available adjustable spreader ranges include:
-
27–36 inches
-
35–48 inches
-
40–60 inches
-
52–84 inches
-
60–96 inches
-
72–120 inches
-
108–144 inches
Spreader selection affects the inside working width and overall configuration of the trench box. Contact Iron Lot with your required trench width, excavation depth, and project location for help reviewing available options.
What Is Included in the Listed Price of this 2-Sided Kit?
The listed base price of $19,565 is for the two sided aluminum configuration:
(4) 120″ Corner Post
(10) 2′ x 10′ MAPS Panels
(6) Adjustable Spreaders 35″ to 48″
(1) Set of Heavy Duty Lifting Lugs
(1) Leg Kit
(80) Pins and Keepers
Discounts may be available depending on quantity and order requirements.
Because freight costs vary based on equipment configuration, shipping origin, destination, and delivery requirements, contact Iron Lot for a complete delivered quote.
Request Pricing and Availability
Iron Lot supplies trench boxes and trench safety equipment to contractors throughout the United States. Contact us for:
-
Current product availability
-
Spreader selection and pricing
-
Multiple-unit quotations
-
Freight quote and delivery coordination
-
Alternative aluminum trench box options
-
Steel versus aluminum trench box comparisons
-
Equipment financing information
Warehouse Shipping Locations: California, Texas, North Carolina
Payment Options:
We accept company check, wire transfer, ACH, and credit card payments. We also offer financing through Ascentium Capital.
Financing: Ascentium Capital offers fast and flexible financing. With their quick and convenient way to purchase equipment, working with Ascentium Capital helps you acquire the funds you need for your equipment purchase. With financing and leasing of up to $2,000,000, Ascentium Capital works with you to make the application process simple and at no obligation.
To learn more about Ascentium Capital and how it can assist you, click image below:
Call Iron Lot at 336-516-8011 or request a quote online for current pricing, availability, and freight information.
Not sure which trench box is right for your project? Compare additional trench boxes for sale, including steel, aluminum, and manhole box options.
